Model

Model Performance Directory

Model Specifications


Model	35	A35	B35	C35	D35	E35	F35	G35	H35	J35	K35	M35	N35	P35	S35	V35	V35A	V35B	33	A33	B33	C33	C33A	E33A	E33C	G33	F33A		36	A36	A36TC	B36TC	Model
Year	1947,1948	1949	1950	1951,1952	1953	1954	1955	1956	1957	1958	1959	1960	1961-62	1963	1964-65	1966	1967-68	1969-	1960	1961	1962-64	1965-67				1971			1968	1969	1978		Year
Price New $	$7,345 / $8,945	$10,000	$12,400	$12,990	$18,990		$19,990	$25,300											$19,995	$21,750	$21,975 -$23,500	23,950 -$27,450
Serial Numbers	D-1 through D-1500	D-1501 through D-2200	D-2201 through D-2680	D-2681 through D-3400, except for D-3293	D-3401 through D-3698	D-3699 through D-3998 & D-3293	D-3999 through D-4391 except for D-4376	D-4392 through D-4865 & D-4376	D-4866 through D-5330, except for D-5062	D-5331 through D-5725 & D-5062	D-5726 through D-6161	D-6162 through D-6561	D-6562 through D-6841	D-6842 through ?					CD-1 to 224 CD-233 & 234 CD-236 & 241 CD-246 to 250	CD-225 to 232 CD-235 to 237 CD-240 to 242 CD-251 to 387	CD-388 to 813	CD-814 to 1118											Serial Numbers
Top speed (mph)	184	184	184	190	190	190	190	194	206	210	210	210	205	205					195	195	195	195											Top speed (mph)
Max. Cruise (mph)	172	170	170	175	180	180	180	184	196	200	200	200	195	195					185	185	185	185											Max. Cruise (mph)
Rate of Climb (fpm)	950	890	890	1100	1100	1100	1100	1300	1250	1250	1170	1170	1150	1150					1010	960	960	930											Rate of Climb (fpm)
Service Ceiling (ft.)	18,000	17,100	17,100	18,000	18,000	18,000	18,000	19,000	19,800	21,300	20,000	20,000	19,200	19,200					19,800	18,400	18,400	17,800											Service Ceiling (ft.)
Landing Speed w/flaps (mph)	55	56	56	55	55	55	55	55	57	57	59	59	60	60																			Landing Speed w/flaps (mph)
Top of Green (MPH)	35 160	A35 160	B35 160	C35 160	D35 160	E35 175	F35 175	G35 175	H35 175	J35 185	K35 185	M35 185	N35 185	P35 185	S35 190	V35 190	V35A 190	V35B 190	33 185	A33 185	B33 185	C33 185	C33A 190	E33A 190	E33C 190	G33 190	F33A 190		36 190	A36 190	A36TC 190	B36TC 193
Vne	202	202	202	202	202	202	202	202	210	225	225	225	225	225	225	225	225	225	225	225	225	225	225			225			234	234	234	237	Vne
Maneuvering	130	130	130	130	130	130	130	130	142	142	142	142	147	148	152	152	152	152	142	147	147	147	152			152			160	160	160	162	Maneuvering
Max. gear lowing speed (mph)	100	125	125	125	125	125	125	140	140	140	140	140	140	165	165	165/175	165	175	140	140	165	165	175			175			175	175	175	177	Max. gear lowing speed (mph)
Max. flap lowing speed (mph)	100	105	105	105	105	105	105	120	120	120	120	120	120	120	130	130	130	140	120	120	120	120	140			140			15@175 Full@140	15@175 Full@140	142	144	Max. flap lowing speed (mph)
Empty weight (lbs.)	1558	1580	1575	1647	1650	1675	1697	1722	1833	1820	1832	1832	1855	1855					1730 lbs	1745 lbs	1745 lbs	1826 lbs	1775	1915	1918	1935	2125						Empty weight (lbs.)
Gross weight (lbs.)	2550	2650	2650	2700	2725	2725	2750	2775	2900	2900	2950	2950	3125	3125					2,900	3,000	3,000	3,050					3400						Gross weight (lbs.)
Useful load (lbs.)	992	1070	1075	1053	1075	1050	1053	1053	1067	1080	1118	1118	1270	1270					1,170	1,255	1,255	1,224											Useful load (lbs.)
Engine (standard)	E185-1	E185-1	E185-8	E185-11	E185-11	E185-11	E185-11	E225-8	O-470-G	IO-470-C	IO-470-C	IO-470-C	IO-470-N	IO-470-N	IO-520-B	IO-520-	IO-520-	IO-520-	IO-470-J	IO-470-J & IO-470-K	IO-470-K	IO-470-K	IO-520-B	IO-520-B	IO-520-BB	IO-470-N	IO-520-BB						Engine (standard)
Wing loading (lbs./sq.ft.)	14.4	14.9	14.9	15.2	15.3	15.3	15.5	15.6	16.3	16.3	16.6	16.3	17.27	17.27																			Wing loading (lbs./sq.ft.)
Power loading(lbs./hp)	15.5	16.1	16.1	14.6	14.7	14.7	14.9	15.0	12.1	11.6	11.8	11.8	12.02	12.02					12.9	13.3	13.3	13.5											Power loading(lbs./hp)
